Панель оператора Beijer HITECH PWS6620T-P

222888 руб.

Предполагаемый срок поставки: 29 мая

Тип экрана: цветной
Диагональ, дюймов: 5.7
Разрешение, пикс.: 320 х 240
Дисплей: 65к цветов
Функции: Compact Flash, дополнительный порт принтера, сенсорный экран

Introductions:

The Plus version of PWS 6620T has a 5.7" graphic touchscreen display with 64K colors and a resolution of 320x240 pixels. The keypad includes one menu key and 5 user-defined function keys. There are two communication ports supporting RS232, RS422 and RS485. The front enclosure is IP65 classified, which means that it is protected against low pressure water jets from any direction. The operator terminal is configured with the intuitive software tool ADP6.

PWS 6620T is also available in Network versions.

Functions:

Animated graphics

Support for ladder or macro functionality

Multi-language support

Real-time clock

Slide-out menu

CF card slot

USB support

Описание
Документы

Панель оператора Beijer HITECH PWS1711-STN 5,7"

Панельоператора Beijer HITECH PWS5610S-S 5,7"

Панель оператора Beijer HITECH PWS5610T-S 5,7"

Панель оператора Beijer HITECH PWS5A00T-P 10,4"

Панельоператора Beijer HITECH PWS6300S-S 3"

Панель оператора Beijer HITECH PWS6400F-P 3,3"

Панель оператора Beijer HITECH PWS6400F-S 3,3"

Панельоператора Beijer HITECH PWS6500S-S 4,7"

Панельоператора Beijer HITECH PWS6560S-S 4,7"

Панель оператора Beijer HITECH PWS6600S-P 5,7"

Панельоператора Beijer HITECH PWS6600S-S 5,7"

Панель оператора Beijer HITECH PWS6600T-P 5,7"

Панель оператора Beijer HITECH PWS6600T-S 5,7"

Панель оператора Beijer HITECH PWS6620S-N 5,7"

Панель оператора Beijer HITECH PWS6620S-P 5,7"

Панель оператора Beijer HITECH PWS6620T-N 5,7"

Панель оператора Beijer HITECH PWS6620T-P 5,7"

Панель оператора Beijer HITECH PWS6710T-N 7.0"

Панель оператора Beijer HITECH PWS6710T-P 7.0"

Панель оператора Beijer HITECH PWS6800C-N 7.5"

Панель оператора Beijer HITECH PWS6800C-P 7.5"

Панель оператора Beijer HITECH PWS6A00T-N 10,4"

Панель оператора Beijer HITECH PWS6A00T-P 10,4"

Панель оператора Beijer HITECH HMI GD17N-BST2R-C1 5.7"

Specifications:

Item	PWS6620T-P	PWS6620T-N
Display Type	Mono TFT LCD
Display Color	64 K colors
Display Size	5.7” (diagonal); display area is 117.2 X 88.4mm
Number of Pixels	320x240; Number of 8x8 characters displayable is 40x30.
Display Adjustment	Via touch panel & VR on the back
Back Light	CCFT; Lifetime 60,000 hours @25 ºC
Touch Screen	Analog
Keypad	1 “Menu” key and 5 user-defined Function keys (F1 ... F5)
Keypad Pressure & Lifetime	350 + - 50gf operating force, Lifetime is over 1 million activations.
Input Power	24VDC + - 15% ; less than 20W
Flash ROM	4M bytes
RAM	512 K bytes
CPU	32 bits RISC
Battery Backed Memory	512 K bytes
RTC	Yes (w/Replaceable Lithium Battery) Notice: When using the machine for the first time, please remember to reset RTC.
Data/Recipe	512K bytes
COM1	9-pin female connector: RS232/RS485
COM2	25-pin female connector: RS232/RS422/RS485
Multi-functional Port	—
Ethernet	—	Yes
Front Panel Seal	IP65
Ambient Temperature	0~50ºC
Storage Temperature	-10~60ºC
Ambient Humidity	10-90%RH(0~40° C),10-60%RH(41-50° C),non-condensing
Vibration Endurance	0.5mm displacement, 10-55Hz, 2 hours per X, Y, and Z-axis directions
Shock Endurance	10G, 11ms three times in each direction of X, Y, and Z axes
CE	EN61000-6-4,EN61000-6-2
External Dimensions (mm)	195(W) x 145(H) x 59.1(D)
Cut-out Dimensions (mm)	185.8 x 135.8
Weight	0.81 Kg
Cooling	Natural cooling
